Cement binder spreader（towed trailer） is mainly suitable for distributing powder materials such as cement, lime and fly ash, and used for cement spraying for highway cold regeneration construction, stabilized soil and a variety of adhesives spraying for roadbed, and can also be used for powder material spraying for other working conditions. cement binder spreader is key equipment for highway cold-in-place regeneration construction it is special equipment for stabilized soil construction, widely used in highway and municipal construction. With characteristics of high efficiency, environmental protection, simple operation, good construction quality and high reliability.
Note: all following products can be supply upper structure
Technical parameters
Item | Unit | Parameter |
Product model | - | 5255TFS |
Working performance parameter | ||
Powder Silo volume | m3 | 16 |
Spreading width | mm | 400～ 2400 |
Spreading density | Kg/㎡ | 5～ 40 |
Spreading precision | % | ±5 |
Min. Working speed | km/h | 2.5 |
Chassis performance parameter | ||
Type | - | HOWO ZZ125V5847F1（China- Ⅴ） |
Engine type | - | MC11.44-60 |
Engine power | kW/（r/min） | 325 / 1900 |
Driving type | - | 6×4 |
Emission standard | - | China Stage V |
Maximum traveling speed | km/h | 80 |
Overall dimension parameter | ||
Minimum ground clearance | mm | 314 |
Approach Angle/Departure Angle | ° | 16 / 13 |
Overall dimension(length× width× height) | mm | 9550×2500×3360 |
Mass parameters of whole machine | ||
Fuel tank | L | 400 |
Curb weight | kg | 17500 |
Total mass | kg | 25000 |
4.2 List of main parts and components
No. | System name | Parts name | Brand |
1 | Chassis system | Chassis | SINOTRUK |
PTO | SINOTRUK | ||
2 | Hydraulic system | Radiator | HANZU |
Piston pump | REXROTH | ||
Control valve group | REXROTH | ||
Radial piston motor | Poclain | ||
Gear pump | Fuxin Beixinxing Co., Ltd. | ||
3 | Electrical system | High speed controller | Northman |
4 | Gas circuit system | Solenoid valve, gas cylinder | Ningbo EMC (kai pu) |
